Table of Content
15 August 2023, Volume 44 Issue 08
  • Fiber Materials
    Preparation and properties of polyphenylene sulfide composite fiber for clothing
    LIAN Dandan, WANG Lei, YANG Yaru, YIN Lixin, GE Chao, LU Jianjun
    Journal of Textile Research. 2023, 44(08):  1-8.  doi:10.13475/j.fzxb.20220308201
    Abstract ( 55 )   HTML ( 13 )   PDF (4567KB) ( 46 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective Special protective clothing are used against high temperature, acid and alkali corrosion, fire and other special environments, and high-performance fibers are essential for special protective clothing. Polyphenylene sulfide (PPS) fiber is a high-performance fiber with excellent mechanical properties, chemical resistance, self-flame retardancy and insulation and other outstanding properties, and it is a suitable raw material for special protective clothing. However, the poor moisture absorption, dyeing performance and light resistance of PPS fiber, limit the applications in apparel.

    Method PPS fibers were modified with sodium polyacrylate (PAAS) and nano-TiO2 to obtain PPS/PAAS/TiO2 composite fibers with better hygroscopic property, dyeing performance and UV resistance. The PPS/PAAS/TiO2 composite masterbatches were prepared by melt blending the vacuum-dried PPS with PAAS and nano-TiO2 using a twin-screw extruder before these composite masterbatches were vacuum dried at 130 ℃ for 13 h. The composite fibers were prepared by a one-step spinning and drawing process using melt spinning. The spinning speed was 800 m/min, the pump supply was 22 g/min, and two-zone drafting was used, with the temperature of each drafting hot plate setting at 88, 102 and 108 ℃, and the drafting multiplier was 3.2. The mechanical properties, moisture absorption properties, dyeing rate, color fastness, and ultraviolet(UV) resistance of the prepared fibers were characterized.

    Results PAAS and nano-TiO2 were able to disperse uniformly in the polyphenylene sulfide (PPS) fiber matrix and form a good cross-compatibility (Fig.2), but when the mass fraction of PAAS exceeded 3%, agglomeration appeared and the poor dispersion led to poor spinnability of PPS composite fibers (Tab. 1). The use of Nano-TiO2 improved the crystallinity of PPS fibers, while PAAS made the glass transition temperature and crystallinity of composite fibers decrease (Fig. 3 and Tab. 2). Increasing the internal free volume and amorphous zone of fibers resulted in a slight decrease in the breaking strength of PPS fibers compared with pure PPS fibers, but the elongation at break increases (Fig. 4). When the mass fraction of PAAS was 2%, the breaking strength of PPS/PAAS/TiO2 composite fiber reached 3.06 cN/dtex and the elongation at break 30.4%, indicating the mechanical properties meeting the requirements of fabrics for apparel. The moisture absorption performance and dyeing performance of the PPS/PAAS/TiO2 composite fiber was improved, the water contact angle decreased with the increase of PAAS content from 73.7° for the pure PPS fiber to 51.2° for the PPS-5 composite fiber (Fig. 5). The standard moisture regain rate increased with the increase of PAAS content from 0.22% for the pure PPS fiber to 3.9% for the PPS-5 composite fiber (Fig. 6). Under the same dyeing conditions, the dyeing rate of PPS-4 composite fiber (90.9%) was twice as high as that of the pure PPS fiber (44.8%) (Fig. 7). The color fastness of PPS/PAAS/TiO2 composite fiber all reached levels 5 and 5 for soaping resistance (Tab. 3), and 6 and 7 for light fastness. The resistance of PPS composite fibers to light aging was significantly improved by addition of nano-TiO2, and the strength remained at more than 85% after 120 h, although there was also strength loss with time (Fig. 8).

    Conclusion The hygroscopic property, dyeing performance and UV resistant of PPS/PAAS/TiO2 composite fibers are all enhanced to a certain extent, partly because of the functional groups of PAAS and nano-TiO2, and partly because of the formation of a good spatial cross-linked network structure with the PPS matrix (Fig. 9). PAAS itself has a long molecular chain entanglement cross-linked structure. There are many reactive —COONa, —COOH groups inside the network, which have super hygroscopic ability. It is proved that nano TiO2 plays a role in preventing UV aging by absorbing and reflecting ultraviolet light and the scattering and shielding ultraviolet light. Water molecules and dyestuffs that penetrate and diffuse into the interior of PPS fibers produce certain hydrogen bonding with the functional groups, resulting in improved moisture regain and color fastness of the fibers. On the basis of maintaining the original properties of PPS fibers, improved moisture absorption, dyeing and UV resistant properties make it a prospective candidate fibre for apparel applications. For further development, it is necessary to focus on the deterioration of the spinnability and mechanical properties of PPS fibers that occur after the PAAS content is increased.

    Design of solar-driven multistage desalination device and investigation of water collection rate
    JIANG Yifei, TIAN Yankuan, DAI Jun, WANG Xueli, LI Faxue, YU Jianyong, GAO Tingting
    Journal of Textile Research. 2023, 44(08):  9-17.  doi:10.13475/j.fzxb.20230206301
    Abstract ( 34 )   HTML ( 12 )   PDF (29937KB) ( 24 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective With low power consumption and environmental friendliness, interfacial solar-driven steam generation technology has been expected to moderate water scarcity from the explosive growth of industry and population. Based on this technology, the multistage desalination devices are prepared for high-efficient freshwater collection.

    Method The 3-D carbon fiber array structure was constructed on the copper plate with excellent thermal conductivity by electrostatic flocking technology, and it was used as a photothermal layer to achieve outstanding light absorption. Non woven fabric with excellent hydrophilicity was used as a water transport channel. After the hydrophobic treatment, the copper plate acted as a water collection layer to rapidly obtain lots of freshwater. Based on the above three components, a ten-stage multistage desalination device with an inclined angle was prepared for high-efficient freshwater collection.

    Results The photothermal layer, which was fabricated with carbon fiber arrays and copper plate by electrostatic flocking technology, can reach a high temperature of 78.4 ℃ for the top surface and 73.7 ℃ for the bottom surface under one-sun irradiation(Fig. 4). It shows the excellent photothermal effect and heat conduction. And it mainly benefits from the design of a three-dimensional array structure and the excellent photothermal properties of carbon fiber. It is seen that after the optimization of materials and fabric weight, the non-woven viscose fabric with 80 g/m2 can reach a wicking height of 18.1 cm within 30 min, and it spreads rapidly to 5 cm in 3 min. It has an excellent ability for water transport and diffusion, and it can continuously supply water for the photothermal layer during solar-vapor generation(Fig. 5, Fig. 7). The optimized copper plate has excellent hydrophobicity after the hydrophobic treatment. The surface of the copper plate has the shape of hierarchical porous petal-like nanostructures. The tightly packed petal-like structures increase the surface roughness of the copper plate and reduce the surface energy, to improve the surface hydrophobicity of the copper plate. At last, its water contact angle can reach 130°. Based on the above three components, firstly, a single-stage device was constructed to optimize the air gap in Fig. 10. And the highest water collection rate of 0.39 kg/(m2·h) was obtained when the air gap was 3 mm. Therefore, with an air gap of 3 mm, a ten-stage multistage desalination device can achieve a water collection rate of 2.05 kg/(m2·h)(Fig. 11). The water collection rate kept unchanged when the number of device stages was further increased.

    Conclusion In our work, with low-cost and simple materials, such as copper plate, carbon fiber and non-woven fabric, a ten-stage multistage desalination device was prepared for high-efficient water collection. With excellent water transport performance, the nonwoven fabric can transport water from bulk water to every photothermal layer for evaporation. Due to the good photothermal effect, the photothermal layer can obtain a high temperature. And with outstanding heat conductivity, the photothermal layer efficiently evaporates the water of non-woven fabric to generate steam. Large amounts of steam condense on the copper sheet to form freshwater. Moreover, the hydrophobic copper plate causes the condensed water to form a waterdrop. Thus, it can reduce latent heat loss. Finally, due to the design of the inclined copper plate, the water droplets slide quickly and are collected. Our multistage seawater desalination device can provide a new idea for the design of efficient solar-driven interfacial devices. It is expected to be one of the effective ways to obtain freshwater in remote and backward areas.

    Preparation and properties of adsorption fiber made from cotton stalk bark microcrystalline cellulose/modified chitosan
    SHAO Yanzheng, SUN Jianghao, WEI Chunyan, LÜ Lihua
    Journal of Textile Research. 2023, 44(08):  18-25.  doi:10.13475/j.fzxb.20211201601
    Abstract ( 17 )   HTML ( 5 )   PDF (7251KB) ( 8 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective The pollution of dye wastewater to the environment seriously harms people's health and is also an important factor restricting the development of textile enterprises. The adsorption method is a promising one for dye wastewater treatment. Natural polymeric cellulose and chitosan are widely used as adsorption materials for wastewater treatment because of the advantages in large capacity for storage, good adsorption, non-toxicity and easy degradation. In this research, an cotton stalk microcrystalline cellulose/chitosan(MCC/CS) adsorption fiber was prepared for the adsorption of Congo Red.

    Method Firstly, modified chitosan (DCS) was prepared by surface modification to CS with formaldehyde as crosslinking agent and 2,5-disulfide diurea as modifier, to improve their adsorption of Congo Red. The modified chitosan process was optimized by the orthogonal test method. Urea solvent method was used to dissolve MCC at low temperature as spinning matrix, DCS was added as insoluble dispersion adsorption material, composite fiber was prepared by wet spinning and freeze-drying, and the spinning process was optimized by the single factor method. Finally, the chemical structure of DCS was analyzed, the morphology and dye adsorption properties of MCC/DCS adsorbed fibers were tested and characterized.

    Results The modification of CS was carried out successfully, where the new C=S characteristic absorption peaks at 1 209 cm-1appear and the absorption peak of -NH2 (2,5-dithiourea, DB) disappeared at 1 640 cm-1 in DCS infrared spectrum. The combination of conditions obtained by orthogonal test for preparation of DCS was optimized, where acetic acid dosage was 55 mL, DB dosage was 0.60 g, CS dosage was 1.0 g, and formaldehyde dosage was 8 mL. The modified chitosan increased the contents of N and S elements, and the changes were obvious. The pore size of the MCC/DCS was larger than the MCC adsorbent fibers, and the modification CS was more beneficial to the adsorption of Congo Red by adsorbent fibers. The fracture strength of MCC/DCS adsorption fiber decreased gradually with the increase of the amount of DCS in the fiber, while the linear density increased gradually because DCS is insoluble in alkaline solution. With the addition of DCS, the viscosity of the spinning solution decreased gradually. When the concentration of dye solution was 60 mg/L, the adsorption capacity of unmodified CS for Congo Red was 13.85 mg/g, and the DCS under optimal conditions was 17.63 mg/g, the adsorption capacity of DCS was increased by 27.29% compared with CS. At the same dye solution concentration, the adsorption capacity of MCC/DCS fiber was 49.55 mg/g, which was 47.82% higher than that of MCC/CS fiber 33.52 mg/g. The analysis of the influencing factors of adsorption performance showed that the adsorption capacity of MCC/DCS adsorption fiber for Congo Red decreased gradually with the increase of adsorption temperature. The adsorption capacity was increased with the adsorption time of MCC/DCS fiber and the change of the initial concentration of dye solution, and the adsorption equilibrium was reached when the concentration of dye solution was 250 mg/L. Ho kinetic model was suitable to simulate the adsorption process of DCS adsorption fibers. The adsorption thermodynamic analysis showed that the Langmuir model was suitable to simulate the adsorption process of DCS adsorbed fibers.

    Conclusion CS was successfully modified with formaldehyde as crosslinking agent and 2, 5-dithiourea as modifier. The modification process of CS was optimized by orthogonal test, and the optimum process was obtained. The MCC was dissolved by urea dissolution system at low temperature as a spinning matrix, coated with DCS powder prepared by the optimized process. Adsorption experiment test results are as follows: when the concentration of dye solution was 60 mg/L, the average removal rate of MCC/DCS fiber Congo Red was 82.58%, and the average removal rate of MCC/CS fiber for Congo Red was 55.87%. The removal rate of MCC/DCS fiber was 47.82% higher than that of MCC/CS fiber, and the expected effect was achieved.

    Preparation and filtration of polyurethane/polyvinyl butyral composite nanofiber membrane
    SHI Jingya, WANG Huijia, YI Yuqing, LI Ni
    Journal of Textile Research. 2023, 44(08):  26-33.  doi:10.13475/j.fzxb.20220302001
    Abstract ( 16 )   HTML ( 7 )   PDF (5599KB) ( 15 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective Air pollution is increasingly a serious global problem. Traditional filtration media are reported to have insufficient mechanical properties and low filtration efficiency. Therefore, in order to reduce the ecological and public health hazards of PM0.3 suspended particles emitted from human production activities, the preparation and property evaluation of the nanofiber membrane with improved mechanical properties and filtration efficiency were reported in the paper.

    Method Polyurethane (PU) with outstanding flexibility was selected as electrospinning polymer material and the solution mass fraction was fixed at 14%. Polyvinyl butyral (PVB) was used as additives to improve morphology, structure, and properties of PU nanofiber membrane. Different PU/PVB composite fiber membrane was fabricated by changing the mass ratios (8∶2, 7∶3, 6∶4) of PU and PVB. After a series of tests such as scanning electron microscope, Fourier transform infrared spectroscope, thermogravimetric analyzer, differential scanning calorimeter, stretching and filtration, the effects of PVB percentage on the morphological structure, chemical structure, mechanical properties, thermal properties, and filtration properties of PU/PVB composite nanofiber membranes were discussed.

    Results The addition of PVB not only increased the spinnability of the fiber solution, but also improved the morphology of the nanofibers(Fig. 1). Under different ratio conditions (8∶2, 7∶3, 6∶4), the average diameter of the fibers was all less than 400 nm, with PU/PVB-8∶2 having the largest average diameter of 385 nm. PU/PVB composite nanofiber membranes presented similar characteristic peaks with PU nanofiber membrane, and the decrease of PU mass share in electrospinning solution leaded to a decreasing trend of the characteristic peaks at 3 318 cm-1, 1 700-1 600 cm-1 and 1 100 cm-1(Fig. 2). PU/PVB composite nanofiber membranes also showed similar decomposition trends and characteristic peaks with those of PU membranes (Fig. 3). These indicated that the addition of PVB did not change chemical structure of PU in the composite membranes. The decomposition onset temperature of PU nanofiber membrane was 249.49 ℃, while the temperature of PU/PVB composite nanofiber membranes was higher than 280 ℃(Tab. 1), indicating that the addition of PVB increased the thermal stability of PU nanofiber membrane. At this time, the introduction of PVB effectively promoted the mixing of molecules within the blend and thus moderating the thermodynamic process and enhancing the thermal stability of the composite nanofiber membranes(Fig. 4). PU nanofiber membrane exhibited a fracture stress of 11 MPa and a fracture strain of 189%, while PU/PVB-8∶2 nanofiber membrane showed mechanical properties with a fracture stress of 16 MPa and a fracture strain of 148%. At this point, the elastic modulus of the composite nanofiber membrane reached a maximum of 8 MPa(Fig. 5), indicating that the mechanical properties of the composite nanofiber membrane were optimal at this mass ratio. The average pore size and porosity of PU nanofiber membrane was 7.24 μm and 55% separately. PU/PVB nanofiber membranes showed decreased pore size ranging from 1.57 to 2.95 μm and increased porosity ranging from 77% to 81% (Tab. 2). For various PU/PVB nanofiber membranes, the pore size of PU/PVB-8∶2 was only 1.78 μm and the pore size distribution was uniform. Compared to the permeability of PU fiber membrane ((63.39±1.83) mm/s), the permeability of the composite nanofiber membranes ranged from 29.04 to 37.57 mm/s. The QF values of PU/PVB composite nanofiber membranes were all greater than 0.02 Pa-1, and the filtration efficiencies for PM0.3 particles were all greater than 95%.

    Conclusion The addition of PVB effectively reduces the diameter of the nanofiber and the pore size of nanofibers membranes, increases the porosity of the nanofiber membranes and improves the thermal, mechanical and filtration properties of the nanofiber membranes. When the mass ratio of PU to PVB is 8∶2, the average diameter of the fibers is 385 nm, the fracture stress is 16 MPa, the fracture strain is 148% and initial decomposition temperature is 289.37 ℃. The composite nanofiber membrane also shows the smallest pore size of 1.78 μm, a permeability of 29.37 mm/s, a filtration efficiency of 98.851% for PM0.3, a resistance pressure drop of 181.7 Pa, and a quality factor of 0.024 6 Pa-1,indicating that it is an ideal medium for microfiltration.

    Fabrication and properties of electrospun nanofibrous membranes from blending collagen peptides/polyethylene glycol
    LIU Xingchen, QIAN Yongfang, LÜ Lihua, WANG Ying
    Journal of Textile Research. 2023, 44(08):  34-40.  doi:10.13475/j.fzxb.20220306001
    Abstract ( 19 )   HTML ( 7 )   PDF (5950KB) ( 11 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective Collagen peptide (COP) is a small molecular weight polypeptide with excellent solubility, but is difficult in filament formation compared with collagen. In this study, polyethylene glycol (PEG) was incorporated with COP, aiming to improve the poor spinnability of COP.

    Method COP was blended with PEG to form the spinning solution with 60% formic acid as solvent. The surface tension and conductivity properties of the solution were measured by a tensiometer and conductivity meter. Scanning electron microscope was utilized to observe the surface morphology of the electrospun nanofibers. The interaction between COP and PEG was analyzed by Fourier transform infrared spectroscope, and the positions and strength distributions of different types of hydrogen bonds were fitted by the Gaussian method in the range of 3 000-3 600 cm-1. The fibrous membranes' thermal characteristics and crystalline structure were also examined using differential scanning calorimeter and X-ray diffractometer(XRD), respectively.

    Results By testing the solution properties of different COP mass fraction blended spinning solutions, it was found that the electrical conductivity and surface tension increased with the increase of COP mass fraction (Tab. 1). The incorporation of PEG improved the spinnability of COP obviously (Fig.1). The average diameter of fibers increased with COP mass fraction increasing and became most uniform when the COP content reached 20%. Moreover, when the mass fraction of COP is 12%, 16%, 20% and 24%, the average diameter of the fiber is 173, 205, 308, 319 nm respectively (Fig.2). FT-IR spectrum Gaussian fitting results showed that COP and PEG formed hydrogen bond, and the intramolecular hydrogen bond decreased while intermolecular hydrogen bond increased. It was discovered that the intramolecular hydrogen bond contact was primarily of OH … OH interaction, with some occurring as cyclic polymers, while the intermolecular hydrogen bond had a variety of OH … O, OH … N and OH … π interactions (Fig.3 and Tab.2). During electrospinning, the endothermic peak of the nanofiber membrane occured at 88 ℃, but the endothermic peaks for COP and PEG were at 100 ℃ and 72 ℃, respectively (Fig.4). From the XRD curves and statistical results of relative crystallinity of COP, PEG and nanofibrous membranes, it was found that COP at 2θ of 21.6° with a broad peak, PEG at 2θ of 19.2° and 23.4°, respectively, had one crystal diffraction peak, and 2θ exhibited a smaller peak in the 26°-28° range (Fig. 5). The nanofiber membrane, there were broad peaks representing COP and crystal diffraction peaks of PEG, respectively, with the addition of COP, the strength increases, and the crystallinity of the fiber membrane after electrospinning also increased (Tab.3).

    Conclusion It was difficult to obtain well formed nanofibers by electrospinning using pure COP, but the addition of PEG was shown to have improved the poor spinnability of COP. The effect of the size of its mass fraction on the surface tension of the spinning fluid fluctuated in a small range due to the low COP molecular weight, while the conductivity increased with increasing COP mass fraction. When the COP mass fraction was 20%, the electrospun fibers exhibit uniform morphology, the relative strength of intermolecular hydrogen bonding was 52.42%, and the crystallinity also reached a maximum (62.53%) with a melting enthalpy of 55.81 J/g. PEG and COP formed hydrogen bond when the solutions were mixed. It is found that after electrospinning the intramolecular hydrogen bond of the fiber membrane decreases, while the intermolecular hydrogen bond increases.

    Preparation and properties of polylactic acid/electret melt-blown nonwovens
    GU Yingshu, ZHU Yanlong, WANG Bin, DONG Zhenfeng, GU Xiaoxia, YANG Changlan, CUI Meng, ZHANG Xiuqin
    Journal of Textile Research. 2023, 44(08):  41-49.  doi:10.13475/j.fzxb.20220302701
    Abstract ( 21 )   HTML ( 4 )   PDF (9962KB) ( 21 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective At present, the problem of air pollution is becoming increasingly serious. Melt-blown nonwovens have the characteristics of fine fibers, high porosity, and small pore size, which can effectively filter out dust and ensure the health of the wearer. Most of the commercially available melt-blown nonwovens are made from polypropylene (PP) due to their excellent filtration performance, but their non-renewable and non-degradable nature of the materials themselves may lead to resource crises and environmental pollution issues. Therefore, the development of green and renewable melt-blown nonwovens is of great significance.

    Method Different types of electrets and polylactic acid(PLA) were selected to prepare PLA/electret composites by melt blending and hot pressing, in order to obtain the best electret SiO2 for PLA. Next, the SiO2 was modified by silane coupling agent KH570 to reduce its agglomeration. As the last step, PLA/SiO2 melt-blown nonwovens were prepared by melt-blown spinning and high pressure in-situ electret technology, and charge storage capacity and air filtration performance of the samples were systematically investigated.

    Result The PLA/electret composite membrane material was successfully prepared using the melt blending method. The PLA/SiO2 membrane material showed an increase in peak intensity at 1 109 cm-1, which is the symmetric stretching vibration peak of Si—O of SiO2, proving the successful composite(Fig.2). The starting thermal decomposition temperature of the PLA/polytetrafluoroethylene(PTFE) membrane material is reduced to around 240 ℃ and the starting thermal decomposition temperature of the PLA/ SiO2 membrane material is set at around 302 ℃, demonstrating that the addition of the electret SiO2 has little effect on the thermal stability of PLA(Fig.3). The electret significantly improves the charge storage capacity of the PLA membrane material, where the surface electrostatic charge is 8.154 kV for the pure PLA membrane material and 17.44 kV for the PLA/ SiO2 membrane material, an increment of up to 113.88%(Fig.3). The residual electrostatic charge on the surface of the PLA membrane material was 3.23 kV after 48 h, while the residual electrostatic charge on the surface of the PLA/ SiO2 membrane material was still as high as 6.34 kV. This demonstrates that the addition of a 1% mass fraction of SiO2 nanoparticles resulted in a better electret effect on the PLA membrane materials. In order to reduce the agglomeration of SiO2, the silane coupling agent KH570 was used to modify the SiO2. The modified SiO2-570 sample shows a C—H vibration peak at a wavelength of 2 930 cm-1 and a weak C=O stretching vibration peak at 1 720 cm-1, both of which are characteristic peaks of KH570 Both of them are characteristic peaks of KH570, which proves that KH570 was successfully grafted onto the SiO2 surface(Fig.5). The modified SiO2-570 nanoparticles are more uniformly dispersed in the PLA matrix, effectively reducing the agglomeration of SiO2(Fig.6). The air filtration efficiency of the PLA melt-blown nonwovens was only 37.5% at a gas flow rate of 32 L/min (Fig.8). The filtration performance of the PLA/SiO2-570 melt-blown nonwovens was superior, with a signifi-cant increase in filtration efficiency to 88.4% and a filtration resistance of only 6.2 Pa, making it more valuable for practical applications.

    Conclusions Firstly, PLA/PTFE, PLA/tourmaline and PLA/SiO2 composite membrane materials were prepared by melt blending method. Among them, the electret SiO2 has less influence on the thermal stability of PLA, and the prepared composite membrane materials have a high surface charge and relatively slow charge decay. Secondly, in order to reduce the agglomeration of SiO2, the silane coupling agent KH570 was successfully grafted onto the SiO2 surface, and the SiO2-570 nanoparticles were more uniformly dispersed in the PLA matrix, significantly reducing the agglomeration of SiO2. Finally, the PLA/SiO2-570 melt-blown nonwovens prepared by melt-blown spinning processing and in situ electret technology has excellent filtration performance, with a significant increase in filtration efficiency to 88.4% and a filtration resistance of only 6.2 Pa. It has great potential for applications in personal protection and air filtration.

    Preparation and filtration properties of firmly bonded multi-layer nanocomposite material
    AN Xue, LIU Taiqi, LI Yan, ZHAO Xiaolong
    Journal of Textile Research. 2023, 44(08):  50-56.  doi:10.13475/j.fzxb.20220305201
    Abstract ( 24 )   HTML ( 4 )   PDF (4166KB) ( 20 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective At present, the development of water treatment technology is a global task,because of the water pollution and the shortage of pure water faced by mankind. In consideration of its superior performance, nanofiber composite filtering materials are widely used to efficiently filter micron sized particulate pollutants in sewage. However, how to increase the filtering efficiency and the adhesion between nanofiber layers and how to evaluate the adhesion are crucial. Therefore, this work is set out to prepare the multilayer materials with high filtering efficiency and adhesion between nanofiber layers and to set up test method for the adhesion.

    Method In this work, a firmly bonded multilayer nanofiber composites was prepared by putting five types of low melting point polymer fibers, which are polyethylene oxide (PEO), polyvinylidene difluoride(PVDF), polystyrene (PS), polymethyl methacrylate(PMMA), metallocene linear low density polyethylene(mLLDPE), together with polyamide 6 (PA6) nanofibers on industrial filter fabrics through eletrospun technology pressed with glass fiber at a designed temperature. Meanwhile, a tensile test method was established to measure the bonding strength of multilayer nanocomposites. The effects of the content of PA6 nanofibers of the materials and initial turbidity value of PS microspheres with a diameter of 1μm solution on the filtration efficiency and filtration flux were also studied.

    Results The low melting point polymer fibers containing PEO, PVDF, PS, PMMA and mLLDPE were made to have different fiber diameters, which are 0.27, 0.36, 0.42, 1.29 and 35.31 μm, respectively(Tab. 1). The multilayer nanocomposite material was successfully prepared by hot pressing the industrial filter cloth spun with low melting point polymer fiber and glass fiber, and the adhesion between nanofiber layers of the multilayer nanocomposite material was significantly improved compared with the common sandwich materials, increasing from 2.6 N/cm2 to 8.2 N/cm2. When the concentration of PS microsphere suspension with a diameter of 1 μm was 80 NTU, the filtration efficiency of multilayer nanofiber composite materials enhances with the increase of the surface density of the PA6 nanofibers(Fig. 5). When the surface density of PA6 nanofibers was constant, the filtration efficiency of the multilayer nanofiber composite materials increaseds with the increase of initial turbidity value of PS microspheres solution, and the filtration efficiency was up to 97.75%. When the initial turbidity of the solution was 160 NTU and the PA6 nanofiber membrane density was 2.5 g/m2, the filtration efficiency of materials on PS microspheres with a diameter of 1μm reached 98.9%, the flux recovery rate was 76.3%, and the interception rate reached above 98%(Tab. 2). With the increase of the surface density of the PA6 nanofiber, the filtration flux of the material to PS microsphere filtrate gradually decreased (Fig. 6). Moreover, a tensile test method was designed to measure the adhesion between nanofiber layers of the multilayer nanocomposite material(Fig. 2).

    Conclusion In conclusion, after the addition of low melting point polymer fiber, a firmly bonded multilayer nanofiber composite was prepared, and a test method for the adhesion of nanofiber composite was established. The multilayer nanofiber composite was found to have high interlayer adhesion, which is significantly higher than the common sandwich purification material, and the composite has good filtration performance for PS microspheres with a diameter of 1 μm. It would have broad application prospects in the field of sewage filtration.

    Textile Engineering
    Tensile property modelling of composite core/sheath yarn with double filaments
    ZHANG Hua, LIU Shuai, YANG Ruihua
    Journal of Textile Research. 2023, 44(08):  57-62.  doi:10.13475/j.fzxb.20220308801
    Abstract ( 28 )   HTML ( 6 )   PDF (2023KB) ( 19 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective In order to analyze and predict the tensile stress-stain relationship of core/sheath composite yarn with double filaments, a viscoelastic tensile model needs to be developed, which would enable numerical prediction of tensile strength of this composite yarn.

    Method The yarn was regarded as a viscoelastic body and its tensile property was shown in the form of the stress-strain corresponding to time. The models commonly used for the research of the tensile fracture mechanism of yarn are varied, such as linear spring, nonlinear spring, nonlinear dashpot, and Maxwell and Kelvin models. Some models above are selected in series or parallel configuration to establish suitable tensile model for core/sheath composite yarn with double filament. Additionally, experimental tests are conducted to verify the correctness of the viscoelastic model.

    Results In this study, a nonlinear viscoelastic model was established to predict the tensile stress-strain relationship of core/sheath composite yarn with double filaments. The tensile properties of the yarn were tested, and different stages of the tensile curve were analyzed. The tensile properties of the composite yarns were simulated and calculated by employing the developed model, and the stress-strain relationship was fitted by applying a polynomial on the foundation of the proposed model. According to the results of tensile tests, the strength of the composite yarn was the highest in comparison with filament and staple yarn. Nevertheless, Young's modulus of composite yarn was the lowest among three types of yarns. In terms of elongation, the fracture elongation of staple yarn was much lower than that of the filament and the composite yarn (Fig. 2). The experimental results revealed that the tensile fracture curve of the composite yarn comprised three stages (Fig. 3). In the first stage, the stress and strain of the yarn showed a linear relationship when only staple yarn understood the load. In the second stage, the stress increased rapidly, and the sheath filament began to be stressed. In the final stage, some monofilaments started to fracture and the strength fluctuated, but the overall strength increased slowly. In accordance with the tensile fracture characteristics, a five-element nonlinear viscoelastic model composed of Kelvin element, Maxwell element, and linear springs were established (Fig.4). Thus, the equation of stress-strain relationship on the core/sheath composite yarn with double filaments was attained based on the model. Then, a scipy.optimize.root function in Python was employed to make a solution to the equation and several parameters were calculated. The viscoelastic tensile model can decently explain the three-stage stress-strain characteristics of the composite yarn tensile curve. The theoretical results were consistent with the experimental results, and the pearson correlation coefficient was greater than 0.999 (Fig. 5).

    Conclusion This paper presented a five-element nonlinear viscoelastic mechanical model to forecast the tensile properties of core/sheath composite yarn with double filaments, according to an experimental and analytical study of the composite yarn. A polynomial function corresponding to the stress-strain relationship of the composite yarn was constructed to analyze and predict the practical tensile curve. The theoretical predictions showed good consistency with the experimental results. The yield stress derived from the model accurately reflected the different stages of the experimental tensile curve. The proposed five-element viscoelastic tensile model can provide theoretical and experimental reference values for the tensile fracture mechanism of core/sheath composite yarn with double filament. Moreover, a novel concept for research on the yarn tensile fracture mechanism is proposed.

    Online detection of yarn breakage based on visual feature enhancement and extraction
    CHEN Taifang, ZHOU Yaqin, WANG Junliang, XU Chuqiao, LI Dongwu
    Journal of Textile Research. 2023, 44(08):  63-72.  doi:10.13475/j.fzxb.20220107001
    Abstract ( 22 )   HTML ( 4 )   PDF (7867KB) ( 7 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective The yarn breakage in ring spinning directly affects the production efficiency and product quality of the yarns. At present, the commonly used automatic yarn break detection mainly employs a single spindle detection method with photoelectricity or magnetoelectricity as the core, both requiring costly modification of the spinning machine and is difficult to implement. Therefore, this paper proposes a break detection method based on machine vision, which provides a new direction for achieving low-cost and high-precision break detection.

    Method An online detection method for yarn breaks based on visual feature reinforcement extraction was proposed. For the problem of difficult yarn feature extraction due to yarn trailing, a neighborhood gradient reinforcement operator was designed for yarn clustering to achieve yarn feature reinforcement. To deal with the problem that yarn targets are small and easily disturbed by environment, an Otsu small target segmentation threshold search method inspired by valley bottom was designed to achieve the segmentation of yarn and background, to extract adaptively yarn features from the yarn image after feature reinforcement, and to enable broken end detection by Euler distance discriminant method.

    Results Inspection devices were installed at a textile factory in Wuxi to collect data, with 1 000 captured images selected for analyze. The factory mainly produces pure cotton high count yarns, with 400 spindles per vehicle. To verify the superiority of the weak feature enhancement proposed in this research, the proposed algorithm was compared with Retinex, homomorphic filtering, and histogram averaging for enhancement experiments. The algorithm developed in this research enhanced the yarn features and effectively suppressed the background areas based on the gradient step characteristics of the yarn (Fig. 8 (e)). Choices of different weights for neighborhood gradient reinforcement operators had different effects on the separation of yarn features and background features. In order to select the optimal weight value, this research adopts the method of controlling variables and conducts experimental comparison on the center weight value between 2 and 3. It was found that the optimal selection range of weight values was between 2.4 and 2.7. Distinct image and dim image enhancement renderings under different weight show clear and blurred images, respectively.

    To verify the effectiveness of the algorithm in extracting yarn features, Otsu, Otsu with added pixel proportion weight, and Otsu threshold segmentation method inspired by valley points were applied to the images. Using this algorithm, it was demonstrated that the proposed algorithm effectively extracted yarn features and a small number of background features at the same pixel level. It was also be demonstrated that the proposed algorithm was able to search effectively for valley thresholds and achieve yarn feature extraction.

    To verify the effectiveness of the feature extraction algorithm, the processing effects and detection results of the Hough transform line extraction method, LSD line detection algorithm, Sobel, Robert and Otsu combined algorithm, Linknet algorithm, and this algorithm were compared(Fig. 13). The results obtained by this algorithm were best fitted to the original image (Fig. 13 (g)).

    The experimental results showed that the detection rate of this method reached 97.3% and the processing efficiency reached 59.76 ms per frame, which was carried out by collecting 1 000 spinning pictures of a spinning factory. It was evident that this method was able to effectively detect yarn breakage in real-time.

    Conclusion The algorithm reported in this paper decomposes the acquisition of yarn features into two parts: reinforcement and extraction, solving the problems of yarn feature dispersion, low proportion of yarn features, and susceptibility to background noise interference in visual ring spinning breakage detection in dynamic environments. Experiments have shown that the algorithm proposed in this article can meet the real-time and accuracy requirements for factory inspection.

    The algorithm currently has difficulty to identify linear noise and yarn features, as the linear filter only considers its morphological features and does not combine its color and morphology. Neural networks can solve problem effectively. In the future, the standard of industrial real-time performance can be achieved by streamlining network models and improving hardware configuration. It is necessary to study how to combine the characteristics of break detection with deep learning to achieve high-precision, robust, and efficient yard breakage detection methods.

    Contact yarn tension measurement method based on convolutional filtering
    PENG Laihu, LIU Jianting, LI Yang, QI Yubao, LI Jianqiang, MAO Muquan
    Journal of Textile Research. 2023, 44(08):  73-80.  doi:10.13475/j.fzxb.20220501401
    Abstract ( 19 )   HTML ( 4 )   PDF (5612KB) ( 3 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective During textile production, yarn tension has an important impact on product quality and production efficiency, and it is necessary to monitor the peak value of yarn tension in real time and obtain the stable value of current yarn tension. The textile equipment measures the yarn tension transmitted by the yarn conveyor in real time through the yarn tension sensor, and transmits the measurement results to the yarn conveyor for regulation. The existing yarn tension sensor can monitor the yarn tension, but because the measured tension signal has problems such as non convergence, large chattering, low accuracy and many burrs, it cannot be applied to the feedback regulation of yarn tension. Otherwise, the measurement error and amplitude will become larger.

    Method When the yarn is fed and knitted into a loop by the yarn feeder and the needle cylinder at a certain speed ratio, the tension will fluctuate with high frequency while keeping relatively constant under the dynamic traction and transportation of the knitting needle and the yarn feeder. On the one hand, the yarn drawn by the knitting needle is a process of intermittently variable speed yarn bending and looping, with periodic motion characteristics. On the other hand, the yarn itself has certain elasticity. Under the action of periodic traction, the stress wave in the yarn body will also be scattered and reflected during the transmission process. The dominant performance is the high-frequency fluctuation of yarn tension. Taking the high-speed seamless underwear machine as an example, the highest frequency of yarn tension measurement is 2.6 kHz, so the tension sensor should meet the highest frequency response requirements. At the same time, on the premise that the yarn tension measurement does not distort and amplify the effective signal, the signal higher than this frequency should be filtered out. This paper first analyzes the characteristics of the problems existing in the existing yarn tension sensors, divides the interference signals into three types, namely, low frequency, high frequency and singular point noise, and then designs three algorithms to deal with them: first, filter the singular noise through the amplitude limiting filtering algorithm (the amplitude of the tension measurement results at a moment is far greater than the actual tension measurement results). High frequency noise is removed by low-pass filtering, and the yarn tension working frequency is taken as the threshold value. The signal above this frequency is defined as high frequency signal; The S-G convolution algorithm is used to remove the low-frequency coupling noise. The low-frequency even coupling signal and the actual working frequency are intertwined, and the low-frequency signal cannot be removed separately. In order to verify the reliability and practicability of the algorithm, an experimental platform for yarn tension measurement was built to compare and analyze the yarn tension measurement data and standard data under constant tension and variable tension conditions.

    Results In order to further verify the accuracy and effectiveness of the algorithm, the yarn conveyor of the control platform changed the yarn tension from 36 cN to 42 cN, and used TENSOMETRIC tension sensor and the sensor designed in this paper to conduct real-time testing of tension fluctuation. It can be seen that the actual measured yarn tension conforms to the mutation law, and the yarn mutation tension fitted by this method is better than the tension fitted by the standard sensor. The results show that this method can control the tension measurement error within 0.6%, which has guiding significance for the yarn tension detection and control system under complex working conditions.

    Conclusion By using the cantilever structure, filtering and convolution algorithm, this paper proposes a contact yarn tension detection method based on convolution filtering algorithm. Firstly, according to the characteristics of the yarn fluctuation of the high-speed seamless underwear machine and the structural characteristics of the cantilever beam, the optimization method of the yarn tension sensor is determined. Then, the acquired data are processed by amplitude limiting filtering, low-pass filtering and S-G convolution algorithm. Finally, the measured results are compared with those of TENSOMETRIC tension sensor through experiments. The tension error is within 0.6% and the standard deviation is within 0.62%. Moreover, this method has good applicability to the detection of yarn sudden change tension, and can meet the real-time measurement of yarn tension under complex working environment.

    Fabric defect detection method using optimized sparse dictionary
    WANG Xiaohu, PAN Ruru, GAO Weidong, ZHOU Jian
    Journal of Textile Research. 2023, 44(08):  81-87.  doi:10.13475/j.fzxb.20220308101
    Abstract ( 16 )   HTML ( 3 )   PDF (4500KB) ( 5 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective Textile fabric defects are generally caused by raw materials (warp or weft yarns), mechanical failures and human factors in the production process, and they seriously impair the quality of final products. At present, most of the defect inspection is conducted by human inspectors, resulting in low efficiency and high laboring cost. Therefore, it is of great significance to apply fast and reliable image processing and machine vision techniques to perform automated defect detection instead of human.

    Method Sparse dictionary learning method has excellent adaptability in representing complex fabrics textures. However, the learning and solving of sparse dictionary take a long time, making it hard to meet the real time requirements in the industrial scenarios. This work proposed a novel dictionary grouping strategy to speed up the sparse coding process in detection stage while guaranteeing the detection accuracy. Firstly, the sliding patch scheme was adopted to learn dictionary from normal fabric samples. Secondly, the learned dictionary was optimized by dividing into groups, and such strategy is to select several optimal dictionary groups with respect to the degree of approximation. Next, the optimized dictionary groups were used to reconstruct a test image to obtain its residual image. As the final step, the reconstructed errors were applied to identify defect areas from normal ones.

    Results To compare the computation time of different algorithms, only the total running time in detection stage was calculated, not including the dictionary learning or dictionary grouping. The experimental results showed that the sparse dictionary algorithm took a longest running time among them, the proposed algorithm took the second longest time, and the unconstrained dictionary used the shortest time(Tabl. 1). The reason that the proposed algorithm was able to reduce most of the time is that the entire algorithm process advances the process of finding the optimal dictionary atoms for the sparse dictionary (sparse coding) and limits the number of dictionary atoms and the reconstruction error, thus significantly reducing the computational effort. The proposed algorithm also achieved a high accuracy rate, slightly lower than the sparse dictionary. The possible reason for it may be that the sparse dictionary do not use all dictionary elements patches each time, but selecting the least number of elements for patch approximation, helping ignore details such as defective areas. The three dictionary learning algorithms have relatively good detection results for various types of defects in plain gray fabrics, and the detection rates are above 90% (Tab. 2). This proposed method has excellent and stable detection for warp defects such as broken warp and knots, and poor detection for weft defects only for few images, which may be caused by their low contrast or minor anomalous defective areas. In summary, the detection accuracy of the proposed method is comparable to that of the unconstrained dictionary and the sparse dictionary in terms of detection accuracy.

    Conclusion In this work, the grouped sparse dictionary method has been proposed to address the real time flaw inspection problem on textile fabric. Aiming at the time consumption of spare coding process, the large amount of spare dictionary are grouped into several groups with small dictionary atoms inside in advance. By converting the time-consuming sparse coding into a least square problem, the proposed method has been proved to be capable of reducing computation time in inspection phase significantly. The experimental results show that this method can combine the advantages of learning time of unconstrained dictionaries and high accuracy of sparse dictionaries, while ensuring real-time and low false detection rate, and has strong adaptability to different types of defects, especially for warp defects with high accuracy and stability.

    Design and performance of warp knit capacitive sensor using silver plated PA/cotton yarns with composite structure
    LI Luhong, ZHAO Boyu, CONG Honglian
    Journal of Textile Research. 2023, 44(08):  88-95.  doi:10.13475/j.fzxb.20220106601
    Abstract ( 23 )   HTML ( 3 )   PDF (6243KB) ( 13 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective Knitted flexible capacitive sensors have been widely studied for their inherent softness and comfort, structural simplicity and low loss. However, most of the sensor electrode materials are exposed to the external environment or in direct contact with the human body, prone to oxidization with long-term use. Moreover, the traditional encapsulation materials used for sensors have poor air permeability, affecting the wearing comfort of human body. Therefore, a knitted composite structure capacitive sensor was proposed to place the electrodes inside the sensor to improve the sensing efficiency of the sensor and the human body experience.

    Method The silver-plated conductive yarn and cotton yarn were used to prepare the double-side-effect electrode using the computerized flat knitting machine with different thickness intervals in the fabric to form the "sandwich structure" capacitive sensor. According to the formula C=(ε0εrS)/d, the change in the distance between the electrodes causes change in capacitance value so as to achieve sensing. The assembled sensor was placed on an electronic universal testing machine for compression experiments, and leads from both ends of the electrodes were connected to the TH2830 LCR digital bridge, and the values were recorded simultaneously.

    Results The electro-mechanical properties, sensitivity, linearity, compression reversibility, hysteresis and repeatability of the sensor were studied and analyzed. The strain-capacitance curve of the sensor showed that with increasing compressive strain the capacitance value increased gradually, which is consistent with the mechanism elaborated in Equation (1) (Fig. 5). As important index for sensing performance, which is usually expressed as the ratio of the relative rate of change of capacitance to the stress, sensitivity of the sensor was characterized. With the gradual increase of the strain value, the sensitivity of the three different thickness sensors demonstrated a gradual increase with two different output characteristics (Fig. 6). The sensor with a thickness of 20 mm achieved a sensitivity of 0.091 kPa-1 within 15 to 50 kPa. The linearity of the sensor at each stage was tested, and it was found that the linearity became worsened as the compression distance was increased (Tab.1). It was also found that although the three thickness sensors produced the maximum height difference at the maximum compression distance, the difference was within the error range and produced useful value (Fig. 7). Hysteresis and repeatability were used to characterize the dynamic performance index of the sensor, and a 20 mm thickness sensor was selected for hysteresis study. Repetitive compression tests with different strains were performed for all thickness sensors (Fig. 8), and the capacitance curves of the output during continuous cyclic stress loading and unloading at the same strain value were consistent overall, and the capacitance output curves of the sensor with 20 mm thickness at different strain values produced less fluctuation and smoother curves. The loading and unloading curves of the sensors had a certain height difference and the maximum hysteresis error of 16.2% took place at the stress value of 8.79 kPa (Fig. 9).

    Conclusion Flexible capacitive sensors of knitted composite structure were prepared by attaching double-side-effect flexible electrodes to three different thicknesses of warp knitted spacer fabrics. The sensors show two different compression output characteristics, with good linearity but lower sensitivity when the strain is in the range of 0-30%, and reduced linearity when the strain range is 30%-60%. With the increase of compression distance, the sensitivity of the sensor is improved. Among them, the larger the thickness of the dielectric layer, the greater the rate of sensitivity increase, which is expected to be applied in the field of large strain limb motion monitoring. Continuous repetitive compression electrical curves of the three different thickness capacitive sensors at different strain values show good repeatability, which also indicates that the designed sensors have good and stable sensing performance. However, the increase in thickness makes the spacer filaments less stiff against bending and increases the sensing hysteresis. This provides some suggestions for the selection of the fabric dielectric layer in the future. To further improve the durability in practical applications, it would be an interesting research to explore the one-piece double-sided effect knitted capacitive sensor in the future.

    Design and three-dimensional simulation of warp knitted spacer fabrics for shoes
    YANG Meiling, JIANG Gaoming, WANG Ting, LI Bingxian
    Journal of Textile Research. 2023, 44(08):  96-102.  doi:10.13475/j.fzxb.20220700601
    Abstract ( 26 )   HTML ( 4 )   PDF (4256KB) ( 6 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective In order to realize the efficient design and simple formation of warp knitted spacer shoe fabrics, the structure and forming principle of shoe fabrics are studied, the application benefit of spacer shoe fabrics is explored, and a design method of spacer shoe material is proposed. With the help of JavaScript and C # computer programming language, fast 3-D simulation of several types of spacer shoe fabrics is carried out with different mesh structures, enriching the choices of the mesh spacer shoe materials.

    Method The functional structure of different areas of the shoe upper was divided, and the matrix model of process design was established, including the mathematical model of yarn padding number and threading cycle. 3-D loop models of 8-point unit loop, 2-point weft lining, 16-point double warp knit structure were constructed. The classification table of the retransmitted structures was listed by using the transverse displacement difference between the needle and the back of the needle. The stress analysis of the rerun loop and the spacer loop was carried out.

    Results The vamp divided into different mesh areas according to functional requirements. Large mesh is used at the toe to improve breathability, small mesh is used at the toe cap and heel area, and tight structure was used at the hem to improve wear resistance (Fig. 1). The construction principle of the 3-D structure of the 4-comb spacer vamp fabric was analyzed. The re-woven weave can be applied to the top and bottom woven surfaces, and the mesh and pattern are only formed on the top or bottom (Fig. 2). The mathematical matrix was used to visually represent the padding number of the spacer shoe fabric and the warp cycle. The knitting action was expressed according to formula of the front and back needle transverse movement difference. Based on the loop control points, the basic 8-point single-needle loop, 16-point double-needle double-needle loop, and 2-point weft lining 3-D models were established, focusing on the hierarchical relationship between the double-needle loop and the two loop on the horizontal single-needle, and the classification table of the double-needle tissue was established according to the transverse movement of the needle back before the needle (Fig. 4, Tab. 1, Fig. 5). According to the formation mechanism of mesh in the spacer shoe material, stress analysis was carried out on both longitudinal lines, and the stress solution of the spacer wire loop in the 3-D space is also carried out (Fig. 6 and Fig. 7). According to different functional requirements, three types of spacer upper fabric processes with different mesh structures were designed, including raw material, knit structure, warp cycle, warp let-off and other parameters. 3-D simulation of three types of spacer mesh upper fabrics was set up using C# and JavaScript programming languages. The comparison between the physical image and the simulation image was shown (Fig. 8, Fig. 9 and Fig. 10).

    Conclusion On the basis of summing up and analyzing the structural characteristics of the interval mesh shoe material, using the practical significance of the mesh structure in the shoe material fabric, the relevant technological mathematical model and geometric model are constructed, the mechanical analysis of the tension on the loop during the fabric knitting and the calculation of the corresponding offset are carried out, and the application of the warp weave structure is discussed, which provides a new idea for the design of the three-layer structure warp knitted shoe material. It provides reliable technical support for three-dimensional mesh simulation of Jacquard shoe fabric.

    Matrix model and design of 3-D tubular woven fabrics with normal weave loom
    WANG Xu, MIN Erjun, LI Shaocong, ZHANG Wenqiang, PENG Xuguang
    Journal of Textile Research. 2023, 44(08):  103-109.  doi:10.13475/j.fzxb.20220502101
    Abstract ( 16 )   HTML ( 4 )   PDF (6089KB) ( 9 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective Tubular composites are widely used in petrochemical, construction, aerospace and other fields. The traditional processing method is winding fiber or fabric and curing after resin impregnation. Because the interlayer is only bonded by resin, it is easy to cause delamination. If the tube wall is made of three-dimensional (3-D) woven fabric, the material's ability to resist delamination would be enhanced. In order to improve the design efficiency based on normal looms, a design method and matrix model of 3-D tubular woven fabric are proposed on the basis of combining the weaving rules of tubular and 3-D woven fabrics.

    Method The weaving method of 3-D tubular woven fabric is "flattening-weaving-restoring". First, the weaving process takes the fabric as a two-layer 3-D woven fabriclinked at both selvedges, and then opened up to form a tubular section after removal from the loom. The weave diagram is divided into three steps. Firstly, the face weave diagram is obtained by selecting 3-D woven fabrics such as orthogonal, angle-interlocking and stitched multi-layer as the tube wall. Secondly, the back weave diagram is obtained by method called "negative and flip". Finally, according to the method of layered weaving, the weave diagram of 3-D tubular woven fabric is determined.

    Results To verify the feasibility of the proposed method, a design example on 3-D tubular woven fabric based on weft through-thickness type orthogonal weave is given (Fig. 3). Firstly, the arrangement ratio of yarn is determine, for example, face warp∶back warp=1∶1, face weft∶back weft=1∶1, then number of warp and weft in a unit of 3-D tubular woven fabric Rgj=12 and Rgw=12. Secondly, the face weave (Fig. 3(a)) is entered at the intersection of odd columns and odd rows and the back weave(Fig. 3(b)) is input at the intersection of even columns and even row. Finally, according to the method of layered weaving, the intersection of the odd columns and even rows is indicated by "⚪" (Fig. 3(c)). The example shows that the proposed method is feasible. Other examples, 3-D tubular woven fabrics using warp through-thickness type angle-interlock weave (Fig. 4) and stitched multilayer type weave (Fig. 5) can both prove the effectiveness of the proposed method

    In order to speed up the design efficiency, a matrix model of 3-D tubular woven fabric is proposed. The elements "1" and "3" represent the floating point of warp and weft of face and back weave, element "0" represents the floating point of warp and weft of face and back weave, and element "5" represents the lifting point of face warp when weaving back weft. Replace the elements of the face weave matrix and adjust the order of the columns of the matrix through the MatLab function to obtain the back weave matrix, then the Kronecker product operation is used to realize the proportional embedding of the face weave matrix in the back weave matrix and the assignment of the lifting point elements in the face warp, so as to obtain the matrix of 3-D tubular woven fabric.

    In order to prove the effectiveness of the proposed matrix model, the following example is given (Fig. 6). Firstly, matrix B (face weave) with 6 rows and 6 columns. The element "0" is replaced by "3" through the find function of the MatLab program, and then the element "1" is replaced by "0" to complete the "negative" effect. Secondly,the fliplr function of the MatLab program is used to realize the left and right order adjustment of the matrix columns to complete the "flip" effect, and the matrix L (back weave) of 6 rows and 6 columns can be obtained. Thirdly, to generate a matrix C with 6 rows and 6 columns, to set elements are all "5", then matrix K1, K2, K3. Finally, according to Equation (1), through the Kronecker product operation of the matrix, the matrix W of 3-D tubular woven fabric can be obtained.

    According to the plotting functions of the MatLab program, different matrix elements print different symbols, such as the elements "1", "3", "5", and "0" are printed "■", "×", "⚪", "□" respectively, which can realize the automatic drawing of the weave diagram.

    Conclusion The design method on weave diagram of 3-D tubular fabric is proposed. Firstly, the 3-D woven fabric is selected as the face weave. Secondly, the back weave is obtained according to the "negative and flip" method. Finally, according to the layered weaving method, the weave diagram of 3-D tubular woven fabric can be constructed. The matrix model of 3-D tubular woven fabric weave is established, which uses different matrix elements to represent the floating point of warp and weft of face and back weave, lifting point of face warp when weaving back weft. Matlab function is used to realize the matrix generation of 3-D tubular woven fabric, that is, through element replacement, sequence adjustment of matrix to realize "negative and flip", matrix Kronecker product operation, and automatic drawing of weave diagram.

    Research on fabric pattern retrieval based on SURF and VLAD feature coding
    ZHAO Wenhao, XIANG Jun, ZHANG Ning, PAN Ruru
    Journal of Textile Research. 2023, 44(08):  110-117.  doi:10.13475/j.fzxb.20220400301
    Abstract ( 15 )   HTML ( 2 )   PDF (6853KB) ( 7 )   Save
    Figures and Tables | References | Related Articles | Metrics

    Objective With the increasing proportion of patterned fabrics produced in fabric manufacturing enterprises, there have been more requirements relating to the production and management of such fabrics, including querying the production materials of imitation, reducing the inventory management costs. The current textile pattern retrieval algorithm has low retrieval efficiency and poor adaptability, which is not conducive to the retrieval of fabric patterns by fabric enterprises. Therefore, a fast and accurate retrieval algorithm for similar patterns was proposed to help enterprises improve the utilization rate of production materials and reduce the cost of fabric inventory management, and promote textile fabric enterprises to enhance the competitiveness of the industry.

    Method This research proposed a textile pattern retrieval algorithm based on SURF (speeded up robust features) and VLAD (vector of locally aggregated descriptors) feature coding. A fabric database with patterns was constructed, and SURF features of the image were extracted to express the image content, before the original fabric was clustered to generate a visual dictionary. The generated visual dictionary encoded the SURF features of the fabric image in the database with VLAD features to aggregate to generate VLAD vectors. On the premise of ensuring the ability of VLAD to express images, principal component analysis was performed on the generated VLAD vectors to reduce the vector dimensions and improve the retrieval efficiency. Finally, the Ball tree algorithm was used to build the index to accelerate the matching speed and improve the retrieval efficiency.

    Results In order to obtain good retrieval performance, the parameters of the algorithm used were optimized. Through the comparison of retrieval precision and time, it was seen that within a certain range the precision of fabrics was improved with the increase of dictionary size K. However, when K was increased to 1 024, the precision only increased slightly with the retrieval time doubled. As the size of the visual dictionary was increased, the complexity and time cost of training the visual dictionary were greatly increased. Considering comprehensively, the dictionary size K=512 was taken in this research. From the perspectives of the retrieval precision and time, it was seen that with the reduction of feature dimensions, the precision of fabrics was constantly decreasing. When the dimension was reduced to 64, the precision of fabrics decreased greatly, with a slow reduction in retrieval time. Considering the effectiveness and time complexity of the algorithm, the feature dimension D=512 was selected in the subsequent experiments of this research. In order to highlight the advantages of the algorithm in this paper, this paper compared the "ORB (Oriented FAST and Rotated BRIEF)+VLAD", "HOG (Histogram of Oriented Gradient)+VLAD", "Color Moments (CM)", "Color Moments+ Gray-level Co-occurrence Matrix" and "Color Histogram+ Gray-level Co-occurrence Matrix" for retrieval verification. The average retrieval accuracy of the algorithm reached 83.5%, the average retrieval time was 0.488s, and the comprehensive performance was better than other algorithms. From the P-R curves, it was evident that the algorithm developed in this research performed the best on the data set built. "HOG+VLAD" was slightly better than "ORB+VLAD", indicating that SURF was able to better describe the characteristics of patterned fabrics than ORB and HOG.

    Conclusion The experimental results show that when the scale of visual dictionary K is 512 and the number of reserved dimensions is 512, the average retrieval accuracy of the algorithm for fabric pattern retrieval is 83.5%, the average retrieval time is 0.488 seconds, and the algorithm has good size invariance and rotation invariance. It has good performance and adaptability for fabric pattern retrieval, which has certain practical significance for the practical application of textile enterprises.
